M100LP Dust Collector

Dust Collector

Depureco M100LP Dust Collector is a Single-phase industrial vacuum with three by-pass motors, an excellent Class M filtering surface (1µ filtration efficiency), and a manual filter cleaning system. It is ideal for dust, solids, and shavings. The vacuum cleaner is fitted with a practical Longopac bagging system.

SUCTION UNIT

The vacuum is generated by 2 by-pass motors. Each motor is managed by an independent switch, permitting the operator to control the intake performance.
The motors are located in a sturdy casing, with an insulating sponge to maintain a low noise level.

FILTERING ELEMENT

The filtration is guaranteed by an M class polyester filter. The star shape enables air to flow through the filter even when it is dirty. The fabric of the filter is classified as M Class (BIA | EN 60335-2-69). This means that all particles till 1 micron are stopped by the filter so as to protect the motors and the operator around the vacuum cleaner.

LONGOPAC

The vacuumed material is collected inside a durable plastic bag named Longopac which is 20 mt. long. The bag is rolled up under the filter chamber and is adjustable for every need. The operator, once the bag is full, will seal the bag by closing it above the collected material, which falls automatically inside the bag during the vacuuming operations. The full part of the bag can subsequently be cut off and disposed of, in total safety, without any contact occurring between the operator and the material.

Engine
Suction Type: by-pass
Voltage: 230 V
Maximum Vacuum: 250mBAR
Maximum Air Flow: 570 m3/h
Noise Level: 72dB(A)
Engine: 3
Frequency: 50/0Hz
Power: 5.2HP
Weight: 155LB

• Machine Manual
• Technical Data Sheet
